icom ic-v86 VHF 7watt walkie talkie (ORIGINAL)

RM 580.00

Bestbuy Item:

General
Frequency coverage (Guaranteed)
TX:
RX:
144–148 MHz
136–174 MHz
Number of channels207 channels (200 memory channels, 1 call channel and 6 scan edges)
Type of emissionsF2D, F3E (FM, FM-N)
Power supply requirement7.5V DC
Frequency stability±2.5 ppm (–20 ˚C to +60 ˚C, –4 °F to +140 °F)
Current drain
TX (EX Hi/Hi/Mid/Low)
RX (Max. audio)
1.6/1.4/1.0/0.5 A typical
450 mA typ. (INT SP),
200 mA typ. (EXT SP)
Antenna impedance50Ω
Operating temperature range-20°C to 60°C; –4°F to +140°F
Dimensions (W×H×D)
(Projections not included)58.6 × 112 × 30.5 mm, 2.3 × 4.4 × 1.2 in (with BP-298)
Weight (Approximate)300 g, 10.6 oz (with BP-298, FA-B57V)
Transmitter
Output power*7.0/5.5/2.5/0.5 W (EX Hi/Hi/Mid/Low)
Max. frequency deviation± 5.0kHz/±2.5kHz (Wide/Narrow)
Spurious emissionsLess than –60 dB
Ext. microphone connector3-conductor 2.5 (d) mm (1⁄10")⁄2.2 kΩ
Receiver
Sensitivity–124 dBm typical
Squelch sensitivity–126 dBm typical
Selectivity (Wide / Narrow)75 dB typical / 70 dB typ.
Intermodulation65 dB typical
Ext. speaker connector3-conductor 3.5 (d) mm (1⁄8")/ 8Ω
Audio output power
   Internal SP (w/8Ω load)
   External SP (w/8Ω load)
1500 mW typical
550 mW typical
*7w output from 144 – 160 MHz. 5.5w 136 – 144 MHz/160 – 174 MHz
